Microsoft Orleans is best known for its virtual actor model, where 🌾 Grains represent independent units of state and behavior.
But when your app needs to react to real-time data — like stock price updates, chat messages 💬, IoT sensor readings 🌡️, or live game events 🎮 — you need something more dynamic.
That’s where Orleans Streams come in.
⚙️ What Are Orleans Streams?
Think of Orleans Streams as event pipelines that connect grains, clients, and external systems.
They provide a pub/sub model — where producers publish messages to a stream, and consumers subscribe to it — without knowing about each other.
💡 Why Streams Matter
Without streams, grains would need to constantly poll each other or send direct messages, tightly coupling components and creating unnecessary complexity.
With streams:
- Grains publish events to named channels.
- Other grains (or clients) subscribe to those events.
- Orleans ensures messages are delivered reliably, respecting ordering within a stream.
Streams are
- Reactive
- Grains react to events instead of constantly polling for updates.
- The system pushes messages to subscribers whenever something happens.
- Example: A ChatRoomGrain pushes new messages to subscribed UserGrains automatically — no user polling is needed.
- Benefits: reduces latency, CPU usage, and simplifies logic.
- Asynchronous
- Sending and receiving messages happens in the background.
- Publishers don’t wait for consumers to process the message.
- Example:
OnNextAsyncis called on the stream, and subscribers process it independently. - Benefits: highly scalable, non-blocking, and allows many grains to handle thousands of messages concurrently.
- Location-Transparent
- Grains can publish and subscribe without knowing each other’s physical location in the cluster.
- Example: A
SensorGrainon one node can send data to aDashboardGrainon another node — Orleans takes care of routing. - Benefits: simplifies distributed system design and allows grains to migrate, restart, or scale without breaking event delivery.
🚀 Getting Started with Streams
Let’s walk through a simple example — imagine a Chat Room app.
Each chat room has a unique stream ID, and users (grains) subscribe to it to receive messages.
1️⃣ ChatRoom Grain - Stream publisher 💬
A ChatRoomGrain might look like this:
public interface IChatRoomGrain : IGrainWithGuidKey
{
Task SendMessageAsync(string message);
}
public class ChatRoomGrain : Grain, IChatRoomGrain
{
private readonly IClusterClient _clusterClient;
private IAsyncStream<string>? _stream;
public ChatRoomGrain(IClusterClient clusterClient)
{
_clusterClient = clusterClient;
}
public override Task OnActivateAsync(CancellationToken cancellationToken)
{
var streamProvider = _clusterClient.GetStreamProvider("chat-streams");
_stream = streamProvider.GetStream<string>("ChatNamespace", this.GetPrimaryKey());
return Task.CompletedTask;
}
public async Task SendMessageAsync(string message)
{
await _stream!.OnNextAsync(message);
}
}
When someone sends a message, the grain pushes it into the stream — all subscribers will receive it instantly.
2️⃣ User grain - Stream subscriber 📬
Now, users can subscribe to a chat stream and get real-time updates:
public interface IUserGrain : IGrainWithGuidKey
{
Task Subscribe(Guid chatId);
}
public class UserGrain : Grain, IUserGrain, IAsyncObserver<string>
{
private readonly IClusterClient _clusterClient;
public UserGrain(IClusterClient clusterClient)
{
_clusterClient = clusterClient;
}
public async Task Subscribe(Guid chatId)
{
var provider = _clusterClient.GetStreamProvider("chat-streams");
var stream = provider.GetStream<string>("ChatNamespace", chatId);
await stream.SubscribeAsync(this);
}
Task IAsyncObserver<string>.OnNextAsync(string item, StreamSequenceToken? token)
{
Console.WriteLine($"New message received : {item}");
return Task.CompletedTask;
}
Task IAsyncObserver<string>.OnCompletedAsync() => Task.CompletedTask;
Task IAsyncObserver<string>.OnErrorAsync(Exception ex) => Task.FromException(ex);
}
3️⃣ Define stream and publish a message
using Microsoft.Extensions.DependencyInjection;
using Microsoft.Extensions.Hosting;
using Orleans.Streams;
// Create a generic HostBuilder for hosting the Orleans silo
var builder = new HostBuilder();
// Configure Orleans inside the host
builder.UseOrleans(static siloBuilder =>
{
// 2a. Use localhost clustering (single-node cluster for development/testing)
siloBuilder.UseLocalhostClustering();
// 2b. Add in-memory grain storage for persistence (required for pub/sub bookkeeping)
siloBuilder.AddMemoryGrainStorage("PubSubStore");
// 2c. Add an in-memory stream provider named "chat-streams"
// This enables grains to publish and subscribe to streams
siloBuilder.AddMemoryStreams("chat-streams");
});
// Build and start the host (silo is now running)
using var host = builder.Build();
await host.StartAsync();
// Create a new ChatRoomGrain using the IGrainFactory
// The Guid.NewGuid() ensures a unique chat room ID
var chatRoom = host.Services.GetRequiredService<IGrainFactory>()
.GetGrain<IChatRoomGrain>(Guid.NewGuid());
// Create a new UserGrain using the IGrainFactory
var user = host.Services.GetRequiredService<IGrainFactory>()
.GetGrain<IUserGrain>(Guid.NewGuid());
// Subscribe the user to the chat room’s stream
// The user will now receive any messages sent to this chat room
await user.Subscribe(chatRoom.GetGrainId().GetGuidKey());
// Send a message to the chat room
// This publishes the message to the "chat-streams" stream
// All subscribed users (like the one we just created) will receive it
await chatRoom.SendMessageAsync("Hello world!");
Below diagram illustrates the pub/sub process
┌───────────────┐ ┌───────────────────┐ ┌─────────────┐
│ ChatRoomGrain │ │ Orleans Stream │ │ UserGrain │
│ (Publisher) │──────>│ ("chat-streams") │──────>│ (Subscriber)│
└───────────────┘ └───────────────────┘ └─────────────┘
publishes message delivers message
🧩 When to Use Streams
Use streams when you need:
- Real-time notifications or broadcasts between grains.
- Event-driven workflows (IoT, telemetry, chat, trading).
- Integration with external event systems like Kafka or Azure Event Hubs.
Avoid streams when:
- You need strict request/response semantics — use regular grain method calls instead.
- You need cross-silo transaction guarantees — Orleans Streams don’t support distributed transactions.
